PVC Flexible control cable
Product application
This product is specially used for electronic control equipment, CNC machine, servo, such as mobile devices towline system electrical connections, and is especially suitable for used in industrial environment, indoor dry or wet, the cable if you want to in the outdoor installation must good anti UV protection. The cable has good flexibility and is suitable for low speed and frequent bending. Sheath with low resistance oil mixed PVC, the cable has good oil resistance, and prevent towline cable between the mutual adhesion, can be used for drag chain system, suitable for low frequent bending.
product mix
Conductor: fine strands of bare copper wire
Insulation: special PVC hybrid material or high strength PE material
Core: core wire twisted pair cable and stranding
Core line logo: black core line white digital encoding
Color core line
Outer sheath: special PVC blend oil resistant material (low resistance)
Outer sheath color: Black (or other)
Product characteristics:
Peak operating voltage: 300V
Test voltage: 2000V
Insulation resistance: 20M ohm /KM (20 C)
Minimum bending radius / mobile installation: about 7.5 x D (outside diameter of cable)
The number is not less than 5 million times bending simulation
Maximum moving speed: overhead speed: 0.5M/S
Sliding speed: 0.3M/S
Plus speed: 3.5M/S2
Fixed installation: about 6 x D (external diameter of cable)
Operating temperature / mobile installation: -10 to +80
Operating temperature / fixed installation: -20 to +80
