PUR Oil shielded cable
Product application
The products used in industrial automation, mechanical and electrical equipment, machine tools, and other machinery and equipment, logistics transmission system, production line control system in signal connection, and is especially suitable for used in industrial environment, dry or wet indoor and outdoor fixed installation, PUR sheath enable the electric cable is suitable for extremely harsh industrial environment and corrosive coolants and lubricants occasions, has excellent oil resistance, anti wear performance, anti microbial, anti hydrolysis, chemical corrosion resistance, anti ultraviolet, cable protection is not affected by mechanical stress damage. The copper - plated copper - braided shielded wire has strong anti-interference ability and can guarantee the stability of cable system..
Product structure
Conductor: stranded bare copper wire bundles
Insulation: specially made PVC mixed materials
Core wire: wire stranding
Black core of white digital coding, with yellow wire
The color of the core line, with yellow wire
Black core of white digital coding, yellow wire without
The color of the core line, yellow wire without
Inner jacket: specially made PVC hybrid material
Shielding: tin plated copper braid
Outer jacket: specially made PUR hybrid material
Jacket color: black or gray
Product characteristic
Working voltage: 600V
Test voltage: 3000V
Insulation resistance: 20M ohm /KM (20 C)
Fixed installation: about 6 * D (cable outside diameter)
Working temperature: mobile installation -30 to +80
Fixed installation: -40 to +80
Flame retardant: accord with FT1, VVV-1
