CC-LINK communication cable
CC-LINK communication cable (PVC) 322/ (PUR) 323
Application range:
CC-LINK system is applied in the field of network communication system, which can provide high efficiency and reliable production automation system. Suitable for indoor and outdoor cable trough or casing fixed installation.
Product characteristics:
Overall aluminum foil and tinned copper wire braided shielding has excellent performance of anti electromagnetic interference, PVC sheathed with flame retardant and anti oil characteristics, the pur sheath has excellent resistance to mechanical properties, abrasion resistance, oil resistance, acid and alkali resistance, hydrolysis resistance, corrosion resistant, anti UV, suitable for harsh application environment.
Product structure:
Conductor: stranded bare copper wire
Insulation: foam PE
Core line color: white, yellow, blue
Shield: aluminum + tinned copper braid
Outer sheath: flame retardant PVC, polyurethane PUR
Outer sheath color: Brown
Technical parameters:
Peak working voltage: 300V
Test voltage: 2000V
Characteristic impedance (1MHZ): 110
Conductor resistance 20: 11 /305m
Working temperature: -30 to +70
Minimum bending radius: approximately 15*D (cable diameter)
Flame retardant characteristics: IEC60332-1
