Profibus DP Cable
Application range:
Application of Siemens (Siemens) industrial fieldbus profibusdp field bus system, suitable for indoor and outdoor installation and profibusdp field bus hard line suitable for fixed installation, profibusdp field bus cord suitable for mobile towline system installation.
Characteristic:
Overall aluminum foil and tinned copper wire braided shielding has excellent performance of anti electromagnetic interference, PVC sheathed with flame retardant and anti oil characteristics, the pur sheath has excellent resistance to mechanical properties, abrasion resistance, oil resistance, suitable for harsh environment.
Structure:
Conductor: solid bare copper wire or a plurality of strands of bare copper
Insulation: special foam PE
Core line color: green, red
Shield: aluminum +85% coverage tinned copper shield
Outer sheath: flame retardant PVC, or PUR
Jacket color: Purple
Technical parameters:
The characteristic impedance (F = 3MHZ): 150 + 15.
Loop resistance: maximum 110 /KM
Working temperature: -30 to +70
Working voltage: 300V
Test voltage U:1000V
Minimum bending radius: 10*D (cable diameter)
